This is an angled bracket used with the Permatrack Mounting system. Each bracket gives your Permatrack mounting system a professional finish. These angles have a specially designed retention hole for a pixel to be added to the corner if you desire to have one and will work with bullet and square pixels. They are also available without this retention hole. Both versions are included in the downloadable zip file.
Several common roof pitch angles are available as shown below. Custom angles can be created as well.
ROOF PITCH |
ANGLE |
---|---|
1:12 | 170.480 |
2:12 | 161.080 |
3:12 | 151.920 |
4:12 | 143.140 |
5:12 | 134.760 |
6:12 | 126.860 |
7:12 | 119.480 |
8:12 | 112.620 |
9:12 | 106.260 |
10:12 | 100.380 |
11:12 | 94.980 |
12:12 | 90.000 |
13:12 | 85.420 |
14:12 | 81.200 |
15:12 | 77.320 |
16:12 | 73.740 |
We are delighted to have partnered with the great folks at Permatrack.US as an exclusive supplier of Permatrack Mounting brackets. The Permatrack Mounting system can be purchased from their website, www.permatrack.us.
Try Before You Buy:
This option is for those of you that are not certain if this clip will work for you. Feel free to download the file for free and if it works out for you, please consider supporting us by returning and purchasing the file.
Terms & Conditions:
Recommended Printer Settings:
These are the minimum print settings that we recommend you use
Dimensions:
Length: Varies
Width: 45mm
Height: 31mm
